GSH-1-60 is a compact high temperature spray hank yarn dyeing machine designed for small-lot polyester hank yarn, polyester blended yarn and other suitable synthetic yarn processing. It is commonly used for recipe testing, shade approval, trial production and limited-quantity orders where high temperature dyeing is required.
The machine is equipped with one 600mm spray pipe, 140℃ design temperature, 135℃ maximum working temperature and 0.4MPa maximum working pressure. Its recommended loading capacity is around 5kg, depending on yarn material, hank size, yarn density and process requirement.
Model :
GSH-1-60Payment :
T/T;LCProduct Origin :
ChinaShipping Port :
Shanghai Port, ChinaHS Code :
8451400000Quick Answer: GSH-1-60 is a 5kg high temperature spray hank yarn dyeing machine for small-lot polyester, polyester blended yarn and other suitable synthetic yarn processing.
This compact model is designed for recipe testing, shade approval and small trial batches where high temperature dyeing is required. It has one 600mm spray pipe, 140℃ design temperature, 135℃ maximum working temperature and 0.4MPa maximum working pressure.
The GSH-1-60 is a compact high temperature spray dyeing unit mainly used for polyester hank yarn, polyester blended yarn and other suitable synthetic yarns that need high temperature processing. It is suitable for dyeing factories that need a small-capacity machine for sample confirmation, trial production or limited-quantity orders.
In practical production, this compact model is often used for recipe testing, shade approval and small trial batches. After the dyeing result is confirmed, the customer can select a suitable production model according to the regular batch quantity and output requirement.
The actual loading quantity may vary according to yarn material, hank size, yarn density, loading method and process requirement. For this reason, model selection should be based on the real yarn and process, not only on nominal capacity.
The final configuration should match the yarn material, hank size, loading weight, heating condition and factory operation habit. The following data is for standard GSH-1-60 reference.
| Model | GSH-1-60 |
| Machine Type | High temperature spray dyeing machine for hank yarn |
| Recommended Loading Capacity | Around 5kg, subject to yarn material, hank size, yarn density and process requirement |
| Number of Spray Pipe | 1 pipe |
| Spray Pipe Length | 600mm |
| Main Power | 1.1kW |
| Design Temperature | 140℃ |
| Max. Working Temperature | 135℃ |
| Max. Working Pressure | 0.4MPa |
| Standard Power Supply | 380V / 50Hz |
| Main Material | SUS304 stainless steel for dye liquor contact parts |
Note: Configuration can be adjusted according to yarn material, process requirement, heating method, control system and local power supply.
GSH-1-60 uses a spray circulation structure. During operation, dye liquor passes through the spray pipe and repeatedly contacts the yarn. The circulation condition can be adjusted according to material, hank density and process requirement.
For small polyester or polyester blended batches, stable liquor circulation is important. Weak circulation may affect liquor exchange, while excessive force may influence some yarn structures. For this reason, selection should not be based only on nominal loading. Yarn type, hank form and process conditions should also be checked.
Water consumption, dyeing time, shade performance and final result are affected by yarn material, loading density, liquor ratio, recipe, heating condition and operator control. We recommend confirming the real process before selecting the final model.
For small-capacity high temperature processing, customers may compare spray type and immersion type machines. These two structures are used for different production priorities.
| Item | GSH-1-60 Spray Type | TY-VH-50 Immersion Type |
|---|---|---|
| Dyeing Method | Spray circulation | Immersion dyeing |
| Main Focus | Compact operation and process standardization | Better hank shape, roundness and soft appearance |
| Typical Use | Recipe testing, shade approval and small trial batches | Special yarn orders with higher appearance requirements |
If your main target is compact high temperature sample dyeing and easier operation, GSH-1-60 spray type is usually the first model to consider. If your yarn requires better hank roundness and softer final appearance, you can also compare it with the 5kg immersion type model.
If this small-capacity model cannot meet your regular production demand, GSH-2-60 can be considered as the next option. It has two spray pipes and is more suitable when the expected loading quantity or output requirement is higher.
| Model | Recommended Loading | No. of Spray Pipe | Typical Use |
|---|---|---|---|
| GSH-1-60 | Around 5kg, depending on yarn and loading condition | 1 pipe | Recipe testing and very small batch production |
| GSH-2-60 | Around 10kg, depending on yarn and loading condition | 2 pipes | Small production batches with higher output requirement |
You can check the 10kg spray type model if your regular batch is larger than this model's recommended loading range.
Before recommending a final model, we need to understand your yarn and dyeing process. This helps avoid wrong selection and reduces later production adjustment risk.
If you are not sure whether to choose normal temperature spray type, high temperature spray type or immersion type, you can read our hank yarn dyeing machine application guide before confirming the model.
GSH-1-60 is mainly used for polyester hank yarn, polyester blended yarn and other suitable synthetic yarns that require high temperature dyeing. For cotton, viscose, wool or other yarns that can be dyed at normal temperature, a normal temperature model may be more suitable.
No. Around 5kg is a recommended reference loading. The actual loading quantity depends on yarn material, hank size, yarn density, loading method and process requirement. We recommend confirming the yarn details before final model selection.
The design temperature is 140℃, and the maximum working temperature is 135℃. This distinction is important when checking whether the machine is suitable for polyester, polyester blended yarn or other high temperature dyeing processes.
Spray type is usually selected for compact operation, recipe testing and small trial batches. Immersion type may be considered when the yarn requires better hank roundness, softer appearance or higher appearance consistency after dyeing.
If the expected loading quantity or output requirement is higher than the GSH-1-60 recommended range, GSH-2-60 can be considered. It has two spray pipes and is more suitable for small production batches with higher output demand.
Please provide yarn material, hank photo, approximate hank size, expected loading quantity, required dyeing temperature, heating method, factory voltage and destination country. These details help us check whether this model is suitable or whether another configuration should be recommended.
Share your yarn material, expected loading quantity, target process and local power supply. Our engineer will check whether GSH-1-60 is suitable, or whether another model is more appropriate for your production.
