Hank Dyeing Machine - Normal Temperature

You are in:

/ Home /Hank Dyeing Machine - Normal Temperature /Good price high quality textile hank yarn dyeing machine normal pressure
cotton yarn dyeing machine

Good price high quality textile hank yarn dyeing machine normal pressure

Normal pressure spray hank yarn dyeing machine is suitable for bleaching, refining, dyeing, washing and after-treatment process of twisted filament, single yarn, rayon, mercerized cotton yarn, silk, silk and cashmere in hank yarn form.

  • Model :

    SH-60

  • Payment :

    LC;T/T

  • Product Origin :

    China

  • Shipping Port :

    Shanghai Port, China
Inquiry now

cotton yarn dyeing machine

PRODUCT FEATURE

  • Textile spray type skein hank dyeing machine is suitable dyeing: chevilled silk, sub-thread spun yarn, rayon, viscose, pure cotton, cotton acrylic blend, mercerized cotton yarn (silk cotton yarn/mercerized cotton spun yarn), spun silk(yarn), silk, cashmere, blended yarn and so on
  • It is suitable for bleaching, refining, dyeing, washing and postprocessing.
  • Hank yarn dyeing machine is equipped with large flow special purpose water pump, have better performance and high efficiency, longer service time, the most important is the water quantity is stable during dyeing.
  • The new designed spray type dyeing pipe, after dyeing, reduce the yarn loss.
  • It structure optimization, liquor ratio (bath ratio) as low as 1:6-7, save cost.
  • Hank yarn dyeing machine is equipped with smart controller and frequency inverter



STANDARD STRUCTURE

  • Main body of dyeing machine is high quality corrosion resistant stainless steel
  • Stainless steel spray pipe
  • With transmission device for spray pipe
  • Large flow water pump
  • Dyestuff tank : mixing, heating, backflow, feeding and cleaning
  • Internal type heating exchanger
  • Water level indicator
  • Hank yarn load in and out device; cleaning spray pipe tool



OPTIONAL CONFIGURATION

  • Auto/Semi Auto control system
  • Dosing system
  • The second inflow and the second drain
  • Dyestuff tank with auto system
  • The length of spray pipe: L=1200mm/1500mm/2000mm



SPECIFICATION

SH SERIES NORMAL TEMPERATURE NORMAL PRESSURE HANK YARN DYEING MACHINE
MODEL CAPACITY(KG) NO. OF SPRAY PIPE MAIN POWER(KW)
SH-1-65 3 1 1.1
SH-2-65 7 2 1.1
SH-2-120 14 2 1.5
SH-4-120 28 4 3
SH-6-120 42 6 4
SH-10-150 100 10 5.5
SH-20-150 200 20 11
SH-30-150 300 30 18.5
SH-40-150 400 40 22
