Textile high temperature dyeing machine for hank yarn in China

PRODUCT FEATURE

• GSH high temperature hank spray dyeing machine is designed as low energy-losing, high lift, and large quantity water flowing. Low liquor ratio reduce the cost of production. It is suitable for dyeing polyester yarn, twisted terylene ,embroidery thread ,etc.
• GSH high pressure dyeing machine for hank yarn with cover are locked with lockong ring and air pressure seal device.
• The weir flow type jet tube integrates the functions of spraying liquid, turning yarn and shifting into a whole, avoiding the twisting and knotting phenomenon of Hank yarn, and the dyeing loss is very low.
• Heating form: direct heating and indirect heating by steam.
• High pressure hank dyeing machine with reliable electrical protection system and mechanical safety interlocking device.

STANDARD STRUCTURE

• All the parts contacting dye liquor are made of high quality corrosion resistance stainless steel.
• Dyetuff tank: mixing, heating, water inflow, backflow and add dyestuff.
• Hank yarn load in and out hook; cleaning spray pipe brush.
• High performance stainless steel mixing-flow pump.
• Automatic water leverl indicator.
• Stainless steel spray pipe.

OPTIONAL CONFIGURATION

• Semi auto / auto system
• Dosing system
• Spray pipe length: L= 600/1500/1800/2000mm
• Auto opening/closing cover system

SPECIFICATION

GSH HIGH TEMPERATURE HIGH PRESSURE HANK YARN DYEING MACHINE
