Top-running L-type overflow fabric dyeing machine for knitted synthetic and velvet home textile fabric. Liquor ratio 1:6–7, up to 300 kg/tube, 50–2000 GSM.
Model :
TY-JL636Payment :
LC;T/TProduct Origin :
ChinaShipping Port :
Shanghai Port, ChinaHS Code :
8451400000
TY-JL636 series is top-running L-type fabric dyeing machine developed for knitted synthetic fabric, elastic knitted fabric and velvet / brushed home textile fabric. For dye houses/factories processing these fabric categories, TY-JL636 is one of the practical machine choice thanks to its gentle fabric handling, efficient dye liquor exchange and wide fabric adaptability.
This fabric dyeing equipment features low liquor ratio design of 1:6–7, helping save a large amount of process water and reduce steam required for heating. Equipped with large-flow, low-spray-pressure overflow nozzle, TY-JL636 is widely used for knitted fabric dyeing. The maximum loading capacity can reach up to 300 kg per tube, and it is suitable for dyeing fabric ranging from 50 GSM to 2000 GSM.
Knitted fabric are naturally more elastic and looser in structure than woven fabric, making them more sensitive to tension, friction and crease formation during dyeing. TY-JL636 is designed to match the characteristics of knitted fabric and improve dyeing performance through relaxed fabric transport and efficient dye liquor exchange.
TY-JL636 integrates key components including the main dyeing body, overflow / jet nozzle system, fabric guide system, heat exchanger, circulation pump and dosing pump group. Through coordinated liquor flow and controlled fabric movement, the machine supports stable dye liquor penetration and efficient processing performance.
| Working pressure | 0.4 MPa |
| Max. design temperature | 140℃ |
| Rate of temperature rise | 20–140℃, 35 min |
| Rate of temperature drop | 140–70℃, 30 min |
| Cloth running speed | 0–450 m/min |
TY-JL636 Overflow High Temperature Fabric Dyeing Machine (Low Tension)
| MODEL | TY-JL636-250 | TY-JL636-500 | TY-JL636-1000 |
|---|---|---|---|
| CAPACITY (kg) | 250 | 500 | 1000 |
| NO. OF TUBES | 1 | 2 | 4 |
| POWER | 19.45 KW | 37.35 KW | 67.5 KW |
| DIMENSION (L×W×H mm) | 8090×1700×3080 | 8090×3100×3080 | 8090×6050×3080 |
Below are reference photos for packing/shipment preparation and project support.
To recommend the right TY-JL636 configuration and quotation faster, please send the following information:
| 1. Fabric type & composition | For example: knitted polyester, nylon, velvet, brushed home textile fabric, cotton knit, blended fabric, etc. |
| 2. Fabric GSM range & width | Please share the usual GSM range and fabric width for model selection. |
| 3. Batch loading requirement | Required loading per batch (kg) and expected loading per tube. |
| 4. Dyeing process & dye class / target temperature | Immersion dyeing, reactive dye, acid dye (or others), and target temperature requirement. |
| 5. Utilities available | Steam or electric heating, voltage and other utility information. |
| 6. Main issue to solve | For example: crease marks, fabric deformation, poor levelness, shade repeatability, water/steam saving, etc. |
TY-JL636 is mainly designed for knitted synthetic fabric and velvet / brushed home textile fabric.
Knitted fabric is more elastic and sensitive to tension. The top-running concept helps keep fabric movement more relaxed, reducing deformation, overstretching and crease formation during dyeing.
TY-JL636 with low liquor ratio design of 1:6–7, helping reduce water use and steam demand for heating.
Maximum loading capacity can reach up to 300 kg per tube, depending on fabric and process conditions.
TY-JL636 supports wide fabric application range from 50 GSM to 2000 GSM.
