High pressure overflow pure cotton small fabric dyeing machine

PRODUCT FEATURE

• TY-ECO series high pressure knitted fabric dyeing machine is specially designed for dyeing knitted cloth. This type softflow small fabric dyeing machine adopts ultra-low bath ratio overflow dyeing technology, whole dyeing and subsequent washing process is completed by the bath, without air flow to transport fabric. This technique is especially suitable for dyeing knitted fabric, ensure dye distributing on fabric evenly, at the same time, keeping the physical properties of the fabric undamaged.
• Two main pump make differene of fabric running speed and dyeing liquor cross flow speed, decreaseresistance between dye molecules in motion and fabric.
• Dyeing liquor multi-suction direction system, extremely deacrease the liquor ratio and max. bath mixing uniformly.
• Dyestuff feeding and mixing system can dissolve and charge dyestuffs with high efficient, another guarantee for even dyeing.
• New integrated automated management and control task execution components is customized according the fabric.
• New distributor device ensure the fabric with same running speed and same bath in each chamber and different dyeing time, ensure dyeing reproducibility.
• The lifting wheel speed is same with fabric running speed, reduce 80% pressure and tension. This type rope dyeing machine with adjustable softflow nozzle, reducing 30-40% working pressure from nozzle.
• Advanced control system with the best intelligent software realize the full auto dyeing.

BASIC DATA

• Liquor ratio: 1:4.5~6
• Fabric running speed: 300-600m/min
• Max. working temperature: 140℃
• Max. working pressure: 0.35Mpa

SPECIFICATION
