DF241D series high temperature cone yarn dyeing machine is equipped with self-design mixed-flow pump. It is suitable for dyeing polyester yarn, polyester blended yarn, cotton, hemp, acylic, wool and so on.
Model :
DF241DPayment :
T/T; LCProduct Origin :
ChinaShipping Port :
Shanghai Port, China
PRODUCT FEATURE
DF241D series high temperature package yarn dyeing machine is equipped with self-designed mixed-flow pump, with high efficiency and low energy consumption.
According the dyeing requirements of various yarns, the main pump with frequency inverter.
Liquor ratio (1:4-1:6), saving dyes, auxiliaries and energy, reducing the amount of pollution.
New design feeding system, improve the uniformity of color after dyeing.
High pressure bobbin yarn dyeing machine with rapid continuous cleaning system.
STANDARD STRUCTURE
OPTIONAL CONFIGURATION
SPECIFICATION
| MODEL | SPINDLE X LAYER | NO. OF PACKAGES | MAIN POWER(KW) |
| DF241-21 | 1 X (3-5) | 3-5 | 2.2 |
| DF241- 40 | 3 X 4 | 12 | 3.7 |
| DF241- 43 | 4 X 4 | 16 | 5.5 |
| DF241- 43 | 4 X 5 | 20 | 5.5 |
| DF241- 53 | 6 X 5 | 30 | 7.5 |
| DF241- 75 | 12 X 6 | 72 | 11 |
| DF241- 85 | 18 X 6 | 108 | 15 |
| DF241- 85 | 18 X 7 | 126 | 15 |
| DF241- 90 | 19 X 8 | 152 | 18.5 |
| DF241- 110 |
28 X 8 | 224 | 22 |
| DF241- 120 |
36 X 7 | 252 | 22 |
| DF241- 120 |
36 X 8 | 288 | 30 |
| DF241- 130 |
39 X 9 | 351 | 37 |
| DF241- 140 | 46 X 9 | 414 | 37 |
| DF241- 160 |
62 X 9 | 558 | 55 |
| DF241- 170 |
69 X 10 | 690 | 55 |
| DF241- 186 |
90 X 10 | 900 | 75 |
| DF241- 200 |
108 X10 | 1080 | 90 |
| DF241- 200 |
108 X 11 | 1188 | 90 |
| DF241- 200 |
125 X 11 | 1375 | 110 |
